Server Racks & Cabinets

The best rack for the job...

RackSolutions has been manufacturing high quality server racks and cabinets for over 20 years. Whether you need a single rack at home or a thousand in a data center, you’ll find the best that money can buy right here.

On this page, you can filter through popular models which can be customized further in their product pages. If you need something completely unique, contact us.

RS148 Your Customizable Data Center Solution (desktop image)RS148 Your Customizable Data Center Solution (mobile image)
View as Grid List

1-29 out of 29 results found

Set Descending Direction
  1. 42U RS148 Data Center Server Cabinet (148-8423)
    RS148 Data Center Server Cabinet
    0% (0)
    As low as $3080.00 $2800.00
    42-48U of Rackable Space
    Designed for Data Centers
    RS148 Data Center Server Cabinet
  2. RS148 48U Open Frame Data Center Server Cabinet (148-8602)
    RS148 Open Frame Data Center Server Cabinet
    0% (0)
    As low as $1967.90 $1789.00
    48U of Rackable Space
    Designed for Data Centers
    RS148 Open Frame Data Center Server Cabinet
  3. Vertical Mount Wall Racks (1U, 2U, 3U, 4U)
    Vertical Wall Mount Rack 1U - 4U
    0% (0)
    As low as $70.00 $63.64
    Vertical Wall Mount Racks
    1U, 2U, 3U, 4U
    Vertical Wall Mount Rack 1U - 4U
  4. 42U RACK-151 Server Cabinet 600mm x 1000mm (RACK-151-42U)
    Server Cabinet Enclosures
    0% (0)
    As low as $1364.00 $1240.00
    18U - 42U of rackable space Doors and sides are removable and lockable
    Server Cabinet Enclosures
  5. (111-1730) 50U, Rack-111 Post Kit (93.5")
    Open Frame Server Racks
    0% (0)
    As low as $409.60 $372.36
    Open Frame Racks
    5RU - 58RU of Rackable Space
    Open Frame Server Racks
  6. 12U Portable Server Rack - RACK-117-12
    12U Portable Server Rack
    0% (0)
    As low as $510.00 $463.64
    Fits under most desks, tables
    12U rack for server, PC, NAS
    12U Portable Server Rack
  7. Secure Vertical 5U Wall Mount Rack - 23" Deep - Vented Front Doors
    5U Secure Vertical Wall Mounts with Hinged Doors
    0% (0)
    As low as $709.01 $644.55
    5U of Secure Rackable Space
    Mounts 19" equipment
    5U Secure Vertical Wall Mounts with Hinged Doors
  8. 48U 151DC Data Center Rack 24in x 48in (WxD) (151DC-4070)
    Data Center Rack Cabinet Enclosures
    0% (0)
    As low as $2508.00 $2280.00
    Data Center Server Racks
    42U-48U
    Data Center Rack Cabinet Enclosures
  9. Telco Relay 2 Post Rack - 45U Relay Racks - Finish Options
    Telco Relay 2 Post Rack
    0% (0)
    As low as $181.49 $164.99
    Telco Relay 2Post Racks
    24U-45U of Rackable Space
    Telco Relay 2 Post Rack
  10. Open Frame Wall Mount Rack
    Open Frame Wall Mounted Rack
    0% (0)
    As low as $320.00 $290.91
    Wall Mount Racks
    9 size options
    Open Frame Wall Mounted Rack
  11. RackSolutions Data Centre Cabinet 600 mm wide-Front
    Server Rack Cabinet
    0% (0)
    As low as $1625.80 $1478.00
    24U-48U of rackable space
    Secure rack made for server
    Server Rack Cabinet
  12. (111-5383) 8U Open Frame 2 Post Desktop Rack
    Open Frame 2Post Desktop Server Racks
    0% (0)
    As low as $50.00 $45.45
    8U-12U of Rackable Space
    Small Footprint, Low Cost
    Open Frame 2Post Desktop Server Racks
  13. Desktop Rack, 12U x 4U
    Open Frame Desktop Rack
    0% (0)
    As low as $320.00 $290.91
    Highly configurable 19” desktop rack 6 size options available
    Open Frame Desktop Rack
  14. 12U TechEdge Wall Mount Rack 18in Depth (119-6040)
    12U TechEdge Wall Mount Rack 18in Depth
    SKU: 119-6040
    0% (0)
    $239.80 $218.00
    Easily wall mount networking equipment
    Front mount up to 12U of rack equipment
    12U TechEdge Wall Mount Rack 18in Depth
  15. 16U Office Cabinet with Key Lock (151-3500)
    16U Office Cabinet
    0% (0)
    As low as $2183.50 $1985.00
    16U of rackable space
    Secure rack made for servers
    16U Office Cabinet
  16. 45U TechEdge 2Post Rack with Square Holes (121-6512)
    TechEdge 2Post Relay Racks
    0% (0)
    As low as $301.40 $274.00
    Ability to convert into 4 post rack
    Constructed from 13 GA steel
    TechEdge 2Post Relay Racks
  17. OCP 1.5OU Windmill Server Rail (152-5809)
    Open Compute Project (OCP) Products
    0% (0)
    As low as $49.50 $45.00
    Compatible with OCP 21" Equipment
    Open Compute Project (OCP) Products
  18. Wall Mount Rack with Cover
    Wall Mount Rack
    0% (0)
    As low as $142.99 $129.99
    Perfect solution for small office or home office
    1U-2U of Rackable Space
    Wall Mount Rack
  19. 9U Wall Mount Cabinet 600mm x 600mm (WxD) with Glass Door (185-4760)
    Wall Mount Cabinets 600mm x 600mm (WxD) with Glass Doors
    0% (0)
    As low as $299.99 $272.72
    Wall Mount Cabinet
    Single Section
    Wall Mount Cabinets 600mm x 600mm (WxD) with Glass Doors
  20. Transport Case Rack (RACK-TRANSPORT)
    Transport Case Rack
    0% (0)
    As low as $3200.00 $2909.09
    SKB hard cases are shock isolated
    6U & 8U sizes available
    Transport Case Rack
  21. Wall Mount Rack - 15U with Front Door Open
    15U x 11U Open Frame Wall Mount Rack with Side Panels and Swing Door
    SKU: 119-2763
    0% (0)
    $855.80 $778.00
    Wall mount 19" equipment
    Includes sides panels and doors
    15U x 11U Open Frame Wall Mount Rack with Side Panels and Swing Door
  22. 9U Swing Out Wall Mount Cabinet 600mmW x 600mmD with Glass Door (185-4764)
    Swing Out Wall Mount Cabinet
    0% (0)
    As low as $427.90 $389.00
    Mount up 9U, 12U & 15U of rack equipment
    Secure mount with lockable doors and side panels
    Swing Out Wall Mount Cabinet
  23. 48U 151DC Open Frame Data Center Rack 24in x 48in (WxD) (151DC-4488)
    151DC Open Frame Data Center Rack
    0% (0)
    As low as $1397.00 $1270.00
    48U of Rackable Space
    Compatible with any server
    151DC Open Frame Data Center Rack
  24. 47U 141 Colocation Rack with 4 (11U) Compartments (141-4073)
    47U 141 Colocation Rack
    0% (0)
    As low as $4276.80 $3888.00
    Colocation Cabinet 2,3,4
    Secure Compartments
    47U 141 Colocation Rack
  25. 12U Front Cover for Open Frame Wall Mount Rack (105-1753) Installed
    Front Cover for Open Frame Wall Mount Rack
    0% (0)
    As low as $171.60 $156.00
    Enclose the front of the Wall Mount Rack
    Protect rack equipment from tampering
    Front Cover for Open Frame Wall Mount Rack
  26. 47U White Colocation Cabinet Rack (141-4767)
    47U 141 White Colocation Rack
    0% (0)
    As low as $1925.00 $1750.00
    Colocation Cabinet 2,3,4
    Secure Compartments
    47U 141 White Colocation Rack
  27. 47U popRack 2Post 23in EIA with 4 (11U) Compartments (141-2379)
    popRack
    0% (0)
    As low as $3934.70 $3577.00
    Tenants cannot remove compartment dividers
    4 secure compartments
    popRack
  28. 2U Secure Wall Mount Rack (2URACK-116)
    2U Secure Wall Mount Rack
    SKU: 2URACK-116
    0% (0)
    $369.99 $336.35
    Perfect solution for small office spaces
    Mounts flush to flat surface
    2U Secure Wall Mount Rack
  29. Rack 111 Accessories
    Open Frame Rack 111 Accessories
    0% (0)
    As low as $17.60 $16.00
    Protect and Organize Your Equipment
    Control Airflow
    Open Frame Rack 111 Accessories
per page

Which Server Rack or Cabinet is best for you?

There are a significant number of variables that you need to be familiar with before investing in a server rack. On top of that, server needs can change over time, so you will need to plan for what might be necessary in the future.

Arguably, the most important metrics in server racks are U space, depth, width, weight capacity. Additionally, depending on the type of equipment, you will need to choose between a 2 post (teleco) or 4 post rack with an open or enclosed frame.

Below, we will summarize important information that will help you make a purchasing decision, but feel free to contact us for help or specialized needs.

How much U space do I need?

U space, or rack units, are a standard by which height in racks and IT equipment is measured by. This metric is based off of 3 rack holes which add up to 1.75 inches.

You need to be familiar with how much U space your equipment will take up in order to save money while making sure everything fits. If you end up with too much open space, you might need blanking panels to keep airflow contained.

We carry racks with U heights from 1U to 90U, meaning that there are plenty of options for the home, office or data center.

How much depth does my rack need?

Depth is just as important as U space because not having enough room means that you might be returning or reselling your rack. When considering necessary depth, you will need to not only find the dimensions for your current hardware, but any hardware that you might get in the future.

RackSolutions’ server racks range from 0-50 inches. The average depth for a server rack is about 36”. On top of making sure there is enough depth for your equipment, make sure that any rails or shelves you would like to use are compatible.

What internal and external width do I need?

Most server chassis have a width of 19 or 23 inches in order to keep things consistent. On our website, width is filtered by which server chassis the rack can fit.

External width is relevant to the space that the rack takes up inside of a room. It can extend up to 32 inches to provide space for cable management, power supplies and other accessories. This can be customized more through individual item pages.

To summarize, check the width of your equipment to determine your internal width and your floor space for the external width.

How can I find the weight capacity?

All of our racks have static load capacity ratings on their product pages. You will need to estimate the sum of your equipment's weight in order to determine what capacity your rack will need.

Purchasing a rack with a higher load capacity than necessary is recommended. One reason is because racks that are capable of being moved have lower weight capacities while in motion. Additionally, it is impossible to predict future weight needs and racks can last much longer than the equipment itself.

What are 2 Post racks used for?

2 Post racks, also known as telco or relay racks are built to house lightweight equipment. This includes routers, switches, controllers or very thin servers. Additionally, 2 post racks are great for mounting shelves that support non rackable equipment.

You can also mount servers on 2 post racks as long as the cumulative weight falls within capacity. We offer plenty of adapters and hybrid rails to help mount servers in 2 post racks.

What are 4 Post racks used for?

4 Post racks are the standard for full servers. They can support thousands of pounds, reach 70U in height and fit any kind of IT equipment that needs to be mounted.

If you need extra security, expandability or a high weight capacity, open or enclosed 4 post racks are the best option. You can purchase them in sizes small enough to fit in an office and large enough to satisfy a data center.

What are the benefits of open frame racks?

Both 4 Post and 2 Post racks have open frame options. This means that all sides of the rack are open to the environment around them. Open frame racks are less expensive than enclosed frame racks, but sacrifice security.

If you want easy access to maintenance, unobstructed airflow and aren’t worried about equipment being tampered with, open frame racks are the most cost effective.

What are the benefits of enclosed frame racks?

Server Racks that are protected from all four corners are called “enclosed frames.” These are available with locks one or two locks on the front, back or both.

Because of the extra metal, enclosed frame racks are a bit more expensive and allow less airflow. The walls allow for more cable management, fans and sensor accessories to be mounted.

About Racksolutions' Server Racks

Our server racks are compatible with all leading OEM servers and equipment, such as Dell, HP and IBM. Open frame racks allow for more airflow and space while enclosed racks enhance security. You will likely want a 2 post (telco) rack if mounting lightweight equipment and a 4 post rack for full sized servers.

Check the height, width and weight requirements of your equipment before making a purchase. Dimensions of our server racks can be found on specific product pages.

+ How much U space do I need?

U space, or rack units, are a standard by which height in racks and IT equipment is measured by. This metric is based off of 3 rack holes which add up to 1.75 inches.

You need to be familiar with how much U space your equipment will take up in order to save money while making sure everything fits. If you end up with too much open space, you might need blanking panels to keep airflow contained.

We carry racks with U heights from 1U to 90U, meaning that there are plenty of options for the home, office or data center.

+ How much depth does my rack need?

Depth is just as important as U space because not having enough room means that you might be returning or reselling your rack. When considering necessary depth, you will need to not only find the dimensions for your current hardware, but any hardware that you might get in the future.

RackSolutions’ server racks range from 0-50 inches. The average depth for a server rack is about 36”. On top of making sure there is enough depth for your equipment, make sure that any rails or shelves you would like to use are compatible.

+ What internal and external width do I need?

Most server chassis have a width of 19 or 23 inches in order to keep things consistent. On our website, width is filtered by which server chassis the rack can fit.

External width is relevant to the space that the rack takes up inside of a room. It can extend up to 32 inches to provide space for cable management, power supplies and other accessories. This can be customized more through individual item pages.

To summarize, check the width of your equipment to determine your internal width and your floor space for the external width.

+ How can I find the weight capacity?

All of our racks have static load capacity ratings on their product pages. You will need to estimate the sum of your equipment's weight in order to determine what capacity your rack will need.

Purchasing a rack with a higher load capacity than necessary is recommended. One reason is because racks that are capable of being moved have lower weight capacities while in motion. Additionally, it is impossible to predict future weight needs and racks can last much longer than the equipment itself.

+ What are 2 Post racks used for?

2 Post racks, also known as telco or relay racks are built to house lightweight equipment. This includes routers, switches, controllers or very thin servers. Additionally, 2 post racks are great for mounting shelves that support non rackable equipment.

You can also mount servers on 2 post racks as long as the cumulative weight falls within capacity. We offer plenty of adapters and hybrid rails to help mount servers in 2 post racks.

+ What are 4 Post racks used for?

4 Post racks are the standard for full servers. They can support thousands of pounds, reach 70U in height and fit any kind of IT equipment that needs to be mounted.

If you need extra security, expandability or a high weight capacity, open or enclosed 4 post racks are the best option. You can purchase them in sizes small enough to fit in an office and large enough to satisfy a data center.

+ What are the benefits of open frame racks?

Both 4 Post and 2 Post racks have open frame options. This means that all sides of the rack are open to the environment around them. Open frame racks are less expensive than enclosed frame racks, but sacrifice security.

If you want easy access to maintenance, unobstructed airflow and aren’t worried about equipment being tampered with, open frame racks are the most cost effective.

+ What are the benefits of enclosed frame racks?

Server Racks that are protected from all four corners are called “enclosed frames.” These are available with locks one or two locks on the front, back or both.

Because of the extra metal, enclosed frame racks are a bit more expensive and allow less airflow. The walls allow for more cable management, fans and sensor accessories to be mounted.

+ About RackSolutions’ Server Racks

Our server racks are compatible with all leading OEM servers and equipment, such as Dell, HP and IBM. Open frame racks allow for more airflow and space while enclosed racks enhance security. You will likely want a 2 post (telco) rack if mounting lightweight equipment and a 4 post rack for full sized servers.

Check the height, width and weight requirements of your equipment before making a purchase. Dimensions of our server racks can be found on specific product pages.
